QUICK OVERVIEW

Folding Flap Fitting F-20 Type2, Spring B, grey RAL 7045 PU1/5

• Holds flap securely in any position
• Extremely smooth movement
• Adjustable spring force
• Integrated adjustable closing damper
• Flap with 3-dimensional adjustment - height, side, angle : Direct adjustment +/- 1.5 mm
• 3-dimensional reveal height, side, depth adjustment : Direct adjustment
• Opening limiter adjustable to 90 degree
• Wide range of applications for many different flap materials
• Fast, tool-free clip fitting of the front
• Pre-assembled Euro screws and positioning pins for easy fixture of the fitting to the side wall
• Extremely strong

Type 2 Spring B - F152145237

• Weight 4.6-13.8 kg

• Range of flaps : Width : 400-1200mm, Height : 520-559mm

 Type 3 Spring B - F152145238

• Weight 4.4 - 12.6 kg
• Range of flaps : Width : 400-1200mm, Height : 560-599 mm

 Type 4 Spring B - F152145240

• Weight 4.1 - 12.1 kg
• Range of flaps : Width : 400-1200mm, Height : 600-649 mm

Type 4 Spring C - F152145241

• Weight 6.8 - 15.8 kg
• Range of flaps : Width : 400-1200mm, Height : 600-649 mm

Type 5 Spring C - F152145243

• Weight 6.7 - 16.9 kg
• Range of flaps : Width : 400-1200mm, Height : 650-699 mm

Type 6 Spring C - F152145244

• Weight 6.5 - 16.4 kg
• Range of flaps : Width : 400-1200mm, Height : 700-749 mm

 Type 7 Spring D - F152145247

• Weight 8.6 - 19.2 kg
• Range of flaps : Width : 400-1200mm, Height : 750-900 mm

F-20 set comprises:

• Note: Please order separately: Tiomos 120 hinges with spring, without damper, and Tiomos mounting plates for top panel.
• Fitting, right and left
• Screw-on bracket for wood, including cover caps
• Cover caps on right and left
• Link hinges

For more information on the installation, do visit Grass product catalogues below:

Mounting Instruction: PDF

Installation Video: Clip

Please go the following link and download product configuration to check the appropriate Type and Spring for your cabinet

http://www.grass.at/downloads-flapsystems.html?L=1
